Model
|
MIG-350MR
|
MIG-500MR
|
MIG-630MR
|
|
Rated input voltage / frequency
|
Three- phase380V（+ / -）10% 50Hz
|
|
Rated input capacity（KVA）
|
17.1
|
27.6
|
36
|
|
Rated input current（A）
|
26
|
42
|
54
|
|
Rated output voltage（V）
|
31.5
|
39
|
44
|
|
Rated load sustainability（%）
|
100
|
100
|
100
|
|
Output no-load voltage（V）
|
70
|
85
|
86
|
|
Output current range（A）
|
20~350
|
20~500
|
20-630
|
|
Output voltage range（V）
|
14~40
|
14~50
|
14~50
|
|
Welding wire diameter（mm）
|
0.8、1.0、1.2
|
1.0、1.2、1.6
|
1.2、1.6、2.0
|
|
Welding wire type
|
Constant voltage characteristic
|
CO₂ carbon steel、carbon steel、carbon steel with chemical core
|
|
Wire feeding type
|
Push/Push-pull
|
|
Cooling mode
|
Water cooling / Air cooling
|
|
Shell protection grade
|
IP21S
|
|
Insulation grade
|
H/B
|
