Model:MIG-X 350/500/630Inverted CO2 gas shielded welding machine

Functions:
MIG/MAG gas shielded welding machine, manual metal-arc welding

Application industry:
Shipbuilding,Container,Construction Machinery,Petrochemical,Steel structure.Shipbuilding, container, engineering machinery, petrochemical industry and steel structure

Features:
It has simple operation;
It has digital display, easy matching of current and voltage and the wide applicable range;
It has the auto-lock function, reducing the labor strength of welders in welding the long welding seams;

It has an excellent performance;
It has the technique to control the waveform, with a small welding spatter and beautiful shaping;
It can extinguish the arc, making the arc striking smooth and rapid;

It has a strong ability to prevent the fluctuation of network voltage;

It is small and light, economic and durable, with a high overall efficiency and energy conservation as well as power saving;

It has abundant peripheral interfaces to match with special machines.

View Big Picture

Technical parameters

Model MIG-350X MIG-500X MIG-630X
Rated input voltage / frequency Three-phase 380V(+ / -)10% 50Hz
Rated input power (KVA) 16.5 27.6 36
Rated input current (A) 25 42 54
Rated output voltage (V) 31.5 39 44
Rated load sustainability (%) 60 60 60
Output no Hoad voltage(V) 68 68 86
Output current range (A) 60~350 60~500 60~630
Output woltage range (V) 15~40 15~50 15~50
Welding wire diameter (mm) 0.8、1.0、1.2 0.8、1.0、1.2、1.6 0.8、1.0、1.2、1.6、2.0
Wire feeding type Push
Welding gun cooling mode Water cooling / Air cooling
Shell protection grade IP21S
Insulation grade H/B
Hand arc welding Welding current 35~350 50~500 63~630
